NAD 375BEE C - Exploded View Parts List

REF.NO PART NO. DESCRIPTION Qty. REF.NO PART NO. DESCRIPTION Qty.
01-37501-00 Poweramp Module Assembly 2 F013 77-062001-1 LED Lens Bezel 2
A001 70-124010-1 Main Heatsink 77-062011-1 LED Lens Bezel Ti:2
F003 J70-124002-0 End Cap L 1
J71-124014-0 Volume Knob Ti:1 S002 61-023106-0 Self Taping Screws STB3×6 35+3
2
2
A002 85-010001-0 Spacer 10 F014 76-062001-1 LED Lens 2
A003 66-018005-0 Thermal Switch Clamping 4 F015 76-076001-0 IR Lens 1
A004 78-124001-0 Insulated Cashion 4 F016 79-124003-0 CR Foam C 1
A005 02-37501-00 Poweramp Module Board NSP 2 F017 79-124002-0 CR Foam B 1
S005 61 023208 0 ×8 20 F018 79 124001 0 1
Self Taping Screws BTB3 CR Foam A
S008 61-023212-0 Self Taping Screw BTB3×12 4 F019 79-062001-0 Rubber Pad 4
S009 61-023215-0 Self Taping Screw BTB3×15 10 F020 66-123003-0 Phone Bracket 1
S010 61-353515-0 Taptite Screw 3×15 16 F021 01-37505-00 Display Board 1
F022 01-37504-10 Standby Board AH:1
01-37504-20 Standby Board C:1
C001 67-124004-2 Old Chassis 1
F023 01-37503-00 Tone Board 1
C002 67-124010-0 Base Cover 1 F024 01-37508-00 Headphone Board 1
C003 67-124011-0 Shielding Box 1 F025 16-37511-00 PCB Pad 2
C004 67-124012-0 Shielding Box Cover 1
C005 66-005007-0 Metal Disc 1 R001 67-124002-1A Rear Panel AH:1
C006 94-124005-0 Transformer label 1 67-124001-1A Rear Panel C:1
C007 75-124001-0 Foot 4 R002 67-124007-0 Rear Panel Plate 2
C008 J78-001002-0 Foot Pad 4 R003 66-010010-0 PCB Bracket 2
C009 73-003001-0 Rotate Knob 1 R004 17-03001-17 Binding Post(Black) 4
C010 69-005001-0 Copper Spacer 5 R005 17-03001-16 Binding Post(Red) 4
C011 69-018001-0 Copper Spacer B 3 R006 A17-07002-07 AC Inlet 1
C012 A18-37571-01 Main Transformer 1 R007 A17-07002-10 AC Outlet AH:1
C013 01-37502-00 Main Board 1 R008 JA20-20000-10 Fuse Holder 1
R009 A11-01101-03 Rocker Switch 1
R010 01-37512-00 BP Board 1
F001
J70-124001-4A Fascia 1
R011 02-37507-00 RS232 Board 1
J70-124011-4A Fascia Ti:1
R012 30-63200-00 Shorting Plug 2
F002 67-124005-2 Subfascia 1
67-124005-3 New Subfascia
from S/N greater than H9XC375BEEG04119
R013 30-63700-00 Shorting Plug 2
L
J70-124012-0 End Cap L Ti:1
T001 67-124003-1 Top Cover Graphite
67-124013-1 Top Cover Titanium
67-124003-2 Top Cover Graphite New
1
F004 J70-124003-0 End Cap R 1
67-124013-2 Top Cover Titanium New
Ti:1
J70-124013-0 End Cap R Ti:1
from S/N greater than H9XC375BEEG04119
F005 J71-124004-0 Volume Knob 1 S001 61-023206-0 Self Taping Screws BTB3×6 19
i S T i S ×6
F006 J71-124003-0 Tone Knob 3 61-023106-1 Self Taping Screws STB3×6 Ti:3
J71-124013-0 Tone Knob Ti:3 S003 61-023506-0 Machine Screws MB3×6 18
F007 77-124003-0 Volume Knob Bezel 1 S004 61-023108-0 Self Taping Screws STB3×8 5
77-091013-1 Volume Knob Bezel Ti:1 S005 61-023208-0 Self Taping Screws BTB3×8 21
F008 77-124001-1 Tone Knob Bezel 1 S006 61-073108-0 Self Taping Screws STO3×8 2
77-124011-1 Tone Knob Bezel Ti:1 S007 61-373506-0 Machine Screw M3×6 2
F009 77-124002-2 2P Input Button Bezel 5 S011 61-084108-0 Self Taping Screws STPW4X8 6
77-124012-2 2P Input Button Bezel Ti:5 61-084106-2 Self Taping Screws STPW4X6 Ti:6
F010 J71-124002-0 2P Input Button 5 S012 61-022204-6 Self Taping Screws BTB2.6×4 2
J71-124012-0 2P Input Button Ti:5 S013 63-040506-1 Serrated Lock Washer 8
F011 77-124004-0 Power Button Bezel 1 S014 64-110080-1 Bolts,M10×80 1
77-123014-1 Power Button Bezel Ti:1 S015 63-011020-3 Washers 2
F012 J71-124001-0 Power Button 1 S016 63-021030-0 Spring Washers 1
J71-124011-0 Power Button Ti:1 S017 62-011002-0 Nut,M10 1
- 50 -
EXPLODED VIEW PARTS LIST
A000
67-124004-3 New Chassis
from S/N greater than H9XC375BEEG04119
