NAD 375BEE C - Page 34

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
D227 RECTIFY DIODES 1N4007 33-24007-00 DAX/.400X.100/.039
D228 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D230 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D231 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
TH201 Thyristor
BT151-500R
33-60116-00 TO-220
TH202 Thyristor
BT151-500R
33-60116-00 TO-220
BRIDGE
BR201 Rectifier Bridge
KBU8D
33-30822-03 BRIDGE/1.010X.290/.063
BR202 Rectifier Bridge
KBU8D
33-30822-03 BRIDGE/1.010X.290/.063
BR203 BRIDGE DB104G 33-30142-00 BRIDGE/.400X.500/.047
BR204 BRIDGE DB104G 33-30142-00 BRIDGE/.400X.500/.047
TRANSISTOR
Q201 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q202 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q203 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q204 Transistor MPSA42 31-00042-00 TO92/100/ECB
Q205 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q206 Transistor 2SC4793 J31-04793-00 TO220AB/BCE
Q207 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q208 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q209 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q210 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q211 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q212 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q213 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q214 Transistor KSC2690AYSTU 31-02690-00 TO126/90/ECB
Q215 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q216 MOSFET IRF5210 31-05210-00 TO-220
IC
IC201 RAGULATOR NJM317F 03-00317-04 TO220AB
IC202 RAGULATOR LM337T 03-00337-00 TO220AB
IC203 RAGULATOR NJM317F 03-00317-04 TO220AB
IC204 RAGULATOR LM337T 03-00337-00 TO220AB
IC205 AMP Protector IC HS1237 01-01237-11 SIP.100/8/W.200/L.825
IC206 CMOS Logic CD74HC86E 03-07486-00 DIP14
RESISTOR
F201 Metal Oxide Film Resistor FRX075 A07-70759-01 Pitch=5mm
F202 Metal Oxide Film Resistor FRX075 A07-70759-01 Pitch=5mm
F203 Metal Oxide Film Resistor FRX075 A07-70759-01 Pitch=5mm
R200 Metal Oxide Film Resistor 2.2KΩ, 2W, ±5% 07-30222-04 AX/.600X.200/.039
R201 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R202 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R203 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R204 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R205 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R206 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R207 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R208 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R209 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R210 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R211 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R212 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R213 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R214 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
- 34 -
ELECTRICAL PARTS LIST
