NAD C 326BEE - EXPLODED VIEW PARTS LIST

37
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESC. QTY
1 10-005-0296-90 TRANSFORMER PW TOROIDAL 120V C326 TI-083438 1
(W/ M6 BOLTx1/ NUTx1/DISHx1/RUBBERx2) (RoHS)
[FOR 120V VERSION]
10-005-0297-90 TRANSFORMER PW TOROIDAL 230V C326 TI-083444 1
(W/ M6 BOLTx1/ NUTx1/DISHx1/RUBBERx2) (RoHS)
[FOR 230V VERSION]
2 11-001-0062-90 SWITCH ROCKER 1P1T BLK/BLK 10A/250VAC TV-5 1
UL/CSA/VDE/SEMKO (RoHS)
3 15-004-0093-90 AC SOCKET IEC 320 C18 2 PINS 15A/250V UL/CSA 1
10A/250V VDE SS-7BA-4.8 (RoHS)
4 15-017-0005-90 JUMPER PLUG PITCH 14mm SHORTER (RoHS) 2
5 16-001-0439-93 BINDING POST BASE 4P BLACK T765 R.2 (RoHS) NSP 1** NSP
6 16-001-0546-90 SPEAKER TERMINAL 2P W/O BASE CL1596(N) (ROHS) 2** NSP
7 19-001-0170-90 EXT. HEATSINK 51x173 BLACK (RoHS) 1
8 21-002-0195-90 VOLUME KNOB C326BEE GRAPHITE 1
(RoHS) [FOR GRAPHITE VERSION]
21-002-0202-90 VOLUME KNOB C326BEE TITANIUM 1
(RoHS) [FOR TITANIUM VERSION]
9 21-002-0196-90 TONE KNOB C326BEE GRAPHITE (RoHS) 3
[FOR GRAPHITE VERSION]
21-002-0203-90 TONE KNOB C326BEE TITANIUM (RoHS) 3
[FOR TITANIUM VERSION]
10 21-002-0197-90 IR LENS C326BEE (RoHS) 1
11 21-002-0198-90 2P INPUT BUTTON BEZEL C326BEE 4
GRAPHITE (RoHS) [FOR GRAPHITE VERSION]
21-002-0204-90 2P INPUT BUTTON BEZEL C326BEE 4
TITANIUM (RoHS) [FOR TITANIUM VERSION]
12 21-002-0199-90 2P INPUT BUTTON C326BEE GRAPHITE (RoHS) 4
[FOR GRAPHITE VERSION]
21-002-0205-90 2P INPUT BUTTON C326BEE TITANIUM (RoHS) 4
[FOR TITANIUM VERSION]
13 21-002-0200-90 POWER BUTTON BEZEL C326BEE 1
GRAPHITE (RoHS) [FOR GRAPHITE VERSION]
21-002-0206-90 POWER BUTTON BEZEL C326BEE 1
TITANIUM (RoHS) [FOR TITANIUM VERSION]
14 21-002-0201-90 POWER BUTTON C326BEE GRAPHITE 1
(RoHS) [FOR GRAPHITE VERSION]
21-002-0207-90 POWER BUTTON C326BEE TITANIUM 1
(RoHS) [FOR TITANIUM VERSION]
15 22-001-0367-90 SCREW MACHINE M3 x 6 P/H NI PLT (RoHS) 4
16 22-001-0388-90 MACHINE SCREW M4 X 8 WASHER HEAD NI PLT (RoHS) 4
17 22-001-0403-90 MACHINE SCREW M3X14 P/H W/SPRING&PLAIN 2
WASHER CHROME PLT (RoHS)
18 22-003-0049-90 SCREW TAPTITE 3x8 B/H TYPE “B” BLK PLT (RoHS) 16
19 22-003-0129-90 SCREW TAPTITE 3x8 SMALL K/H TYPE “B” BLK PLT 2
(RoHS)
20 22-003-0138-90 SELF TAPPING SCREW 2X5 WASHER HEAD TYPE B 2
NI PLT (RoHS)
21 22-003-0144-90 SCREW TAPTITE 3.5 X 8.0 B/H TYPE B NI PLT (RoHS) 5
22 22-003-0145-90 SELF TAPPING SCREW DIA2.6 X 8 B/H TYPE A NI PLT 10
(RoHS)
23 22-003-0165-90 SCREW TAPTITE 3 X 8 B/H TYPE B NI PLT (RoHS) 54
24 22-003-0172-90 SCREW TAPTITE 3 X 10 B/H TYPE B BLK PLT (RoHS) 3
25 22-003-0187-90 SCREW MACHINE M4 X 8 B/H BLACK (RoHS) 4
26 22-005-0034-90 WASHER SPRING I/D 4 x O/D 7 x 1 THK (RoHS) 4
