NAD C 326BEE - REAR PANEL; FRONT PANEL VIEW

6
FRONT PANEL
REAR PANEL / FRONT PANEL VIEW
REAR PANEL
1. MP INPUT
2. CD INPUT
3. TUNER INPUT
4. DISC INPUT
5. AUX INPUT
6. VIDEO INPUT
1. STANDBY
2. STANDBY LED
3. SOFT CLIPPING
INDICATOR
4. REMOTE SENSOR
5. PHONES
6. MP SOCKET
7. INPUT SELECTOR
8. TONE DEFEAT
9. TONE CONTROLS
10. BALANCE
11. VOLUME
7. TAPE IN/OUT
8. SUB 1, SUB 2
9. PRE OUT
10. MAIN IN
11. SOFT CLIPPING
12. +12V TRIGGER OUT
13. IR IN/OUT
14. SPEAKERS
15. POWER SWITCH
16. AC MAINS INPUT
1
111095 6 7 8
2 3 4
1 432 5 6 7 8 9 10 12 1615141311
