NAD C 326BEE - Packing Diagram

39
PACKING DIAGRAM & PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 24-003-0127-90 POLYBAG MAUNAL (RoHS) 1
1 24-004-1936-92 CARD WARRANTY NAD MODELS R.1 (RoHS) 1
1 24-004-2385-92 C326BEE OWNER’S MANUAL R.1 (RoHS) 1
2 24-003-0119-90 POLYBAG CORD (RoHS) 1
2 17-004-0026-90 AC Cord 110V 2 PINS 125V/13A SJT AWG18/3C UL/CSA 1
L=2M (RoHS) [FOR AH VERSION]
17-004-0027-90 AC CORD CE 2 PINS 16A 250V LF L=2M H05VV-F 2G 1
0.75 BLACK (RoHS) [FOR C, CT VERSION]
3 24-006-0992-90 POLYFOAM ENDCAP C326BEE (RoHS) 2
4 24-003-0119-90 POLYBAG MAIN UNIT (RoHS) 1
4 24-003-0166-90 PROTECTIVE COVER (RoHS) 1
4 40-001-0108-90 DESSICANT BAG 20g 1
5 28-008-0010-90 REMOTE CONTROLLER NAD SR 8 (RoHS) 1
6 25-007-0024-90 BATTERY AA 1.5V R6P AA (RoHS) 2
7 24-001-0729-90 MASTER CARTON BOX C326BEE (RoHS) 1
