WIRING DIAGRAM PARTS LIST
Item Database Part Number Description Remark
1 17-012-4444-90 CABLE ASSY 3 WAYS AWG18 3.96P PIN 2 VOID PSU BD-J605,
UL1672 L=170mm (B/BR) (RoHS) J606
2 17-012-4422-90 CABLE ASSY 9 WAYS AWG=26 2.5P UL1007 PSU BD-J601A
L=240mm (RoHS)
3 17-012-2956-90 Cable assy 1 way AWG18 UL1007 BLACK L=100mm PHONE BD-J510
W/RING TERMINAL(RoHS)
4 17-012-4536-90 CABLE ASSY 2 WAYS AWG26 2.5P UL2468 L=700 PHONE BD-
(RoHS) J508A
5 17-012-4424-90 CABLE ASSY 7 WAYS AWG=28 2.0P UL1007 L=350mm KEY BD-J506A
(RoHS)
6 17-012-4425-90 CABLE ASSY 6 WAYS AWG=28 2.0P UL1007 L=410mm KEY BD-J507A
(RoHS)
7 17-012-4426-90 CABLE ASSY 10 WAYS AWG=28 2.0P UL1007 KEY BD-J501A
L=420mm (RoHS)
8 17-012-4427-90 CABLE ASSY 2 WAYS AWG=26 2.5P UL1007 L=80mm KEY BD-J504A
(RoHS)
9 17-012-4423-90 CABLE ASSY 15 WAYS AWG=26 2.5P UL1007/1533 VOL BD-J201A
L=80mm (RoHS)
10 17-012-4420-90 CABLE ASSY 2 WAYS AWG=16 3.96P WHI/RED MAIN BD-J13/
UL1015 L=100mm (RoHS) J16, J14/J15
11 17-012-4428-90 CABLE ASSY 5 WAY AWG26 2.5P UL1007 L=250mm MAIN BD-J101A
(RoHS)
12 17-012-4483-90 CABLE ASSY 1 WAY AWG14 UL1015 L=80mm BLACK MAIN BD-J104,
W/ RING TERMINAL (RoHS) J204
13 17-012-4484-90 CABLE ASSY 1 WAY AWG14 UL1015 L=110mm WHITE MAIN BD-J103
W/ RING TERMINAL (RoHS)
14 17-012-4485-90 CABLE ASSY 1 WAY AWG14 UL1015 L=110mm RED MAIN BD-J203
W/ RING TERMINAL (RoHS)
15 17-012-4521-90 CABLE ASSY 3 WAYS AWG16 3.96P BLACK UL1015 MAIN BD-J7A/
L=200/120/220mm (RoHS) P6/J6A
16 17-012-4529-90 CABLE ASSY 2 WAYS AWG26x1C 2.5P UL1533 L=90 MAIN BD-
(RoHS) J306A/B
17 17-012-4530-90 CABLE ASSY 2 WAYS AWG26x1C 2.5P UL1533 L=110 MAIN BD-
(RoHS) J106A/B
18 17-012-4531-90 CABLE ASSY 2 WAYS AWG26x1C 2.5P UL1533 L=130 MAIN BD-
(RoHS) J105A/B
19 17-012-4532-90 CABLE ASSY 2 WAYS AWG26x1C 2.5P UL1533 L=180 MAIN BD-
(RoHS) J305A/B
