NAD C 730 - Page 27

29
DIODES
D201 4804-1480-C DIODE 1N4148 ATS
D202 4804-0040-1 DIODE 1N4004 AL
D203 4837-5B61-2 DZ 1/2W 5.45-5.73 ROHM
D204,D209,D210 4804-1480-C DIODE 1N4148 ATS
D211 4837-5B11-2 DZ 1/2W 4.94~5.20V ROHM
D212 4804-1480-C DIODE 1N4148 ATS
COIL
L201 1801-220K-M COIL 22µH 10% AL BL7
INFRA-RED SENSOR
M218 4814-3TE2-3 IR SENSOR PIC-12043TE2
VFD
M220 2460-1960-0 VFD SAMSUNG HNA-10SM12
SWITCH
M201-M203, M205-M209 5200-3538-0 SWITCH, TACT SKHHBY 7MM
M210-M211, M213-M217
RESISTORS
R201-R205 4701-821J-C RCF 1/8W 820R 5% ATS
R207, R208 4701-182J-C RCF 1/8W 1.8K 5% ATS
R210, R211 4701-222J-C RCF 1/8W 2.2K 5% ATS
R213, R214 4701-472J-C RCF 1/8W 4.7K 5% ATS
R215 4701-821J-C RCF 1/8W 820R 5% ATS
R216 4701-682J-C RCF 1/8W 6.8K 5% ATS
R218, R219 4701-102J-C RCF 1/8W 1K 5% ATS
R220, R221 4701-471J-C RCF 1/8W 470R 5% ATS
R222 4701-473J-C RCF 1/8W 47K 5% ATS
R230, R231 4701-223J-C RCF 1/8W 22K 5% ATS
R232-R240 4701-103J-C RCF 1/8W 10K 5% ATS
R241-R246 4701-104J-C RCF 1/8W 100K 5% ATS
R247, R248 4701-103J-C RCF 1/8W 10K 5% ATS
R252-R256 4701-103J-C RCF 1/8W 10K 5% ATS
R257, R259 4701-223J-C RCF 1/8W 22K 5% ATS
R260 4701-471J-C RCF 1/8W 470R 5% ATS
R263-R274 4701-104J-C RCF 1/8W 100K 5% ATS
R281-R284 4701-103J-C RCF 1/8W 10K 5% ATS
R285, R286 4701-223J-C RCF 1/8W 22K 5% ATS
R291-R293 4701-103J-C RCF 1/8W 10K 5% ATS
R294 4701-472J-C RCF 1/8W 4.7K 5% ATS
ICs
U201 3131-9750-1 IC LC866448B 8 BIT
U202 3131-7250-0 IC 24C08 8K EEPROM
PRIMARY ASSEMBLY
PC BOARD
07000 PCB-N0941C-PRI PRIMARY ASSEMBLY
PSU ASSEMBLY
PC BOARD
08000 *AH PCB-N0940C-PSU POWER SUPPLY ASSEMBLY
08000 *C PCB-N0941C-PSU POWER SUPPLY ASSEMBLY
CAPACITORS
C106 8910-0091-0 CC 400V 0.01µF +-20% RL
C109 150F-223Z-5-UG CC 50V 0.022µF +80/-20%
Reference No. Part No. Description
