C110 157E-227M-5-PU CE 25V 220µF 20% RL
DIODES
D101 4804-1480-C DIODE 1N4148 ATS
D102-D105 4804-0040-1 DIODE 1N4004 AL
RELAY
M103 4500-0890-0 RELAY 12VDC,250VAC,10A
FUSE
M151 *AH 5120-0037-0 FU T3.15A 250V UL/CSA 5x20MM
M152 *C 5100-2530-1B T2.5A/250V IEC
M154 *AH 5120-0052-0 FUSE T1.6A 250V 5x20MM UL/CSA
TRANSISTOR
Q101 485C-123J-5 TR DTC123JSA ROHM
RESISTOR
R103 *AH
4717-335J-2-S RMF 1/2W 3.3M 5% AT
R104 4707-8R2J-2 RCF 1/2W 8.2R 5% AT
TRANSFORMER
T902 1806-2311-0 EI-35 TRANSFORMER 12V/AC
SPEAKER ASSEMBLY
PC BOARD
09000 *AH PCB-N0940C-SPK SPEAKER ASSEMBLY
09000 *C PCB-N0941C-SPK SPEAKER ASSEMBLY
CAPACITORS
C857, C858 150F-102K-5-IF CC 50V 1000pF 10% RL 5x3
C860, C861 150F-102K-5-IF CC 50V 1000pF 10% RL 5x3
TUNER
ASSEMBLY
PC BOARD
10000 *AH PCB-N0940C-TUN TUNER ASSEMBLY
10000 *C PCB-N0941C-TUN TUNER ASSEMBLY
CAPACITORS
C901 *C 150F-223K-2-FD CC 50V 0.022µF 10% AT
C902-C903 150F-223K-2-FD CC 50V 0.022µF 10% AT
C904 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C906 157D-107M-5-KUK CE 16V 100µF 20% RL
C911 150F-200J-2-FC CC 50V 20pF 5% AT 3.5x2
C912, C913 150F-102K-2-FC CC 50V 1000pF 10% AT 3.5
C914, C915 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C916 150F-331K-2-FC CC 50V 330pF 10% AT 3.5x
C924, C925 15CH-200J-5-GG CTC 0/60 20pF 5% RL 4x4
C926 153F-333J-5-NLM CM 50V 0.033µF 5% RL 7.5
C927 157F-225M-5-GM CE 50V 2.2µF 20% RL 4x7
C928 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C929 157F-224M-5-GM CE 50V 0.22µF 20% RL 4x7
C930 150F-223K-2-FD CC 50V 0.022µF 10% AT
C931 157B-107M-5-KM CE 6.3V 100µF 20% RL 6x7
C932, C941 150F-223K-2-FD CC 50V 0.022µF 10% AT
C942 157D-107M-5-KUK CE 16V 100µF 20% RL
C943 157F-225M-5-GM CE 50V 2.2µF 20% RL 4x7
C944 157F-475M-5-GM CE 50V 4.7µF 20% RL 4x7
C945 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
30
Reference No. Part No. Description
