WARNING
・ Only use grounded power sources. Using a non-speci¿ed Power Cord, the risk of ¿re by over-
heating of the cord is possible.
・ Mis-wiring will cause damage to the CONTROLLER.
・ Be sure to connect the ground wire to the earth ground. Insuf¿cient grounding could cause an
electric shock or malfunction.
・ Tighten the Terminal Screw of the AC Power Input Terminal Block securely. Loose Terminal
Screws to the A
C Power Input Terminal Block will cause over-heating leading to damage and
¿re in the CONTROLLER.
⑮ Plate
When changing the Control Panel from front to rear, remove the Plate from the rear of the CONTROLLER, and
reinstall it on the front of the CONTROLLER where the Control Panel was removed from. When changing the
Control Panel, refer to P68 " 14. CHANGING THE CONTROL PANEL " section.
⑪ AC Power Input
Terminal Block
The AC Power Input Terminal Block connects to the Power Cord terminals. Refer to P65 " 11. POWER CORD
CONNECTION " section.
・Make sure the input power supply is OFF before wiring. If the incoming power supply is ON, it
may cause risk that leads to death or serious injury by electric shock.
・After connecting the Power Cord, be sure to attach the Protective Covers A and B for safety, dust
proo¿ng and electric shock prevention. If the Protective Covers A and B are not attached to the
CONTROLLER, it may lead to the risk of
death or serious injury by electric shock.
DANGER
⑫ Protective Cover A / ⑬ Protective Cover B
The Protective Cover A and B attach to the AC Power Input Terminal Block, for safety dust proofing and
prevention of electric shock.
DANGER
Be sure to attach the Protective Covers A and B before use. Touching a power terminal connection
by mistake may cause risk that leads to death or serious injury by electric shock.
⑭ Securing Band
This band secures the Power Cord connected to the AC Power Input Terminal Block.
CAUTION
Be sure to attach the Protective Covers A and B before use. Without the Protective Covers A and B,
metal chips and other particles may stick to the AC Power Input Terminal Block causing electrical
leakage and damage to the CONTROLLER.
CAUTION
After connecting the Power cord to the AC Power Input Terminal Block, make sure the Power Cord
is secured in place by using the provided Securing Band.
