95
English
② Safety of the Machines when used the Safety Relay Contacts Output
・ When input Emergency Stop Signal that is coupled to opening the movable guard of the Industrial
Machinery, Safety Relay will operate and certainly open the Motor Power Line.
・ Contact output ((SAFE-1A) - (SAFE - 1B), (SAFE - 2A) - (SAFE - 2B)) of the " N - C Contacts " can be
used for detecting the opening of the Motor Power Line.
I
f " N - O Contacts " become welded, contact outputs will certainly maintain OFF (Open) by Forced Guide
Mechanism. Therefore, Safety Relay can be used as an opening signal of movable guard with locking
mechanism for Industrial Machinery.
(2) Speci¿cations
(1) Features
This control panel extension cord is designed so the Operation Panel can be mounted (4m) from the E4000
CONTROLLER.
(2) Speci¿cations
Product Name E4000 SAFETY RELAY BOX
Model E4000 - SRB
Weight 850g (Main Body)
Standard Accessories ・
・
・
Relay Cord・・1pc.
Connector Cover・・2pcs.
Operation Manual・・1set.
・
・
Emergency Stop Cord・・1pc.
Connector Cap・・1pc.
Table. 19
21 - 2 E4000 Control Panel Extension Cord
Product Name E4000 Control Panel Extension Cord
Model E4000 - PEX4
Front Panel Dimensions 73mm x 73mm
Attachable Pitch 63mm x 63mm
Attachable Hole Dimensions ȭ 3.4mm
Cord Length 4m
Standard Accessories ・ Mounting Screw (M3)・・4pcs. ・ Operation Manual・・1set.
Table. 20
(1) Features
This is a convenient stand-off used to mount the E4000 Control Panel Extension Cord to the machines control
for operator convenience.
(2) Speci
¿cations
21 - 3 E4000 BOX for Control Panel
Product Name E4000 BOX for Control Panel
Model E4000 - PB
Weight 216g
Standard Accessories ・
・
・
Case A・・1pc.
Blind Plate・・1pc.
Mounting Screw (M4)・・2pcs.
・
・
・
Case B・・1pc.
Mounting Screw (M3)・・6pcs.
Operation Manual・・1set.
Table. 21
