3/8”(10mm)
2 x N570-0073 (1/4-20 X 3/8”)

Install baery pack below vent slots on le hand panel using magnet supplied with baery pack. Plug wire from LED (lights)
located underneath control panel into wire from baery pack. Install rosserie mount bracket to le side of barbecue as
shown using (2) 1/4 – 20 x 3/8” screws.
