Napoleon LD485 - Parts List and Ordering Form

36
www.napoleongrills.com
    
1 N135-0042-GY1HT le side lid casng x x
2 N385-0129 NAPOLEON logo x x
3 W450-0005 logo spring clips x x
4 N510-0013 black silicone lid bumper x x
5 N685-0012-GY temperature gauge x x
6 N080-0287-GY1HT lid casng cover x x
7 N335-0042L stainless steel lid insert x
N335-0046LK black lid insert x
8 N570-0091 1/4-20 x 1/2” screw x x
9 N010-0720 lid handle x x
10 N135-0043-GY1HT right side lid casng x x
11 N570-0015 lid pivot screw x x
12 N010-0565 hood assembly x
N010-0502 hood assembly x
13 N570-0008 #8 x 1/2” screw x x
14 N570-0073 1/4-20 x 3/8” screw x x
15 N735-0003 1/4” lockwasher x x
16 N520-0023 warming rack x x
17 N305-0063 cooking grids - cast iron x x
N370-0597 cooking grids - wave stainless rod ac ac
18 N305-0057-M05 sear plate x x
19 N010-0722 stainless steel side burner shelf x
20 N570-0076 #8 x 1/2” screw x x
21 N570-0082 1/4-20 x 5/8” screw x x
22 N010-0721-M06 stainless steel side shelf x x
23 N120-0020-GY0TX LUXIDIO side shelf end cap x x
24 N200-0090-M06 infra red rear burner cover x
25 N010-0526P infra red rear burner p
N010-0526N infra red rear burner n
N455-0054 rear burner orice #59 p
N455-0053 rear burner orice #53 n
N720-0053 rear burner supply tube x
N160-0017 clip rear burner tube x
26 N240-0024P rear burner electrode c/w pilot p
N240-0024N rear burner electrode c/w pilot n
27 N080-0206 rear burner electrode cover x
28 Z570-0002 rear burner electrode cover screw x
N615-0011 rear burner electrode cover spacer x
29 N100-0036 main burner x x
30 N080-0281 main burner cross light bracket x x
31 N475-0301-M06 rosserie mount x x
32 N010-0724 base x x
33 N010-0501-M08 drip pan x x
34 N160-0014 grease tray holder x x
35 N185-0001 replacement grease tray aluminium x x
36 N200-0077-GY1SG back cover x
Parts List
