Napoleon LD485 - Page 37

37
www.napoleongrills.com
    
N200-0089-GY1SG back cover x
37 N475-0291-CT control panel x
N475-0323 control panel x
38 N380-0021-CL control knob x x
39 N051-0006 control knob bezel x x
40 N530-0003 1-outlet regulator p p
N345-0001 10 n/g hose c/w quick disconnect n n
41 N010-0716 manifold assembly c/w valves p
N010-0717 manifold assembly c/w valves n
N010-0787 manifold assembly c/w valves p
N010-0786 manifold assembly c/w valves n
42 N720-0044 manifold ex connector x x
43 N255-0027 union ng 3/8” - 3/8” x x
44 N340-0007 tool hook x x
45 N380-0020-CL control knob x
46 N051-0008 control knob bezel x
N720-0055 side burner supply tube x
47 N475-0236-GY1SG le/right side panel cabinet enclosure x x
48 N160-0022 clip door pivot pin x x
49 N475-0293-M06 door panel sanless steel x
N475-0293-BK1SG door panel black x
50 N325-0062 door handle x x
51 N570-0073 1/4-20 x 3/8” screw x x
52 N590-0147-GY1SG boom shelf x x
53 N655-0124-GY1SG front cabinet support x x
54 N475-0271-GY1SG rear cart panel x x
55 N585-0064-GY1SG heat shield x x
56 N105-0013 bushing x x
57 N105-0011 door bushings x x
58 N655-0094-GY1SG tank ring support p p
59 N430-0002 magnec catch x x
N370-0636 main assembly blister pack x x
61 N750-0021B wiring harness led x x
62 N190-0001 baery pack x x
W043-0002 baery “AA’ x x
63 N080-0254G tank inhibitor bracket p p
64 N735-0001 insulated washer x x
65 N105-0001 bushing 7/8” x x
66 N640-0001 hose retainer clip x x
67 N160-0015 propane tank clip p p
68 N130-0012 revolving caster x x
69 N450-0027 locking nut 1/4-20 x x
70 N080-0212-GY1SG stabilizer brackets x x
71 N590-0164-GY1SG condiment basket x x
72 N130-0013 non revolving caster x x
73 N585-0078 heat shield lid x
Parts List
