Insert sear plates into base, posion one over each tube burner with slots down to allow drippings to travel through.

Posion grids and warming rack into base as shown. Rest warming rack on brackets inside hood and grids on front and back
lip of base.

Rotate basket slightly to allow wire to enter the holes in the side panel. Push through and upwards, rotang to allow the
bend in the wire to pass through the holes. Lay basket at against the side panel.

Clip the wire grease tray holder into the two holes located in the center of the back panel. Place the aluminum grease tray
into the grease tray holder.
