1-2 General Information
1.4 Instrument Items
PMM 7010 includes the following items:
• EMI Receiver
• External power supply/battery charger;
• Flexible black cover/accessories holding;
• RS232 cable, 2m;
• USB cable, 2m;
• Operating manual;
• PMM 7010 Utility Software on Software Media;
• Certificate of Compliance;
• Return for Repair Form.
1.5 Optional
accessories
PMM 7010 can be used with several optional accessories, the most common
being the following:
• PMM 9010-RMA Rack Mount Adapter for Rack 19”
• L2-16B: single phase AMN, 16A;
• L3-32: four lines, 3-phase, 32A LISN, (50Ω//5 Ω+50μH);
• L3-64: four lines, 3-phase, 63A LISN, (50Ω//5 Ω+50μH);
• L3-64/690: four lines, 3-phase, 63A LISN, (50Ω//5 Ω+50μH);
• L3-100: four lines, 3-phase, 100A LISN, (50Ω//5 Ω+50μH);
• L1-150M: single line LISN, 150A (50Ω//1 Ω+5μH);
• L1-150M1: single line LISN, 150A (50Ω//1 Ω+5μH);
• L1-500: single phase, 500A LISN, (50Ω//5 Ω+50μH);
• L3-500: four lines, 3-phase, 500A LISN, (50Ω//5 Ω+50μH);
• L2-D: Delta LISN for telecom, 2A, 150Ω
• SBRF4 RF Switching Box (Switching Box for LISNs and Loop Antennas)
• LISN Service Kit (AC-BNC adapter for LISNs verification and calibration)
• SHC-1/1000: 35 dB CISPR Voltage probe, 1500Ω;
• SHC-2/1000: 30 dB CISPR Voltage probe, 1500Ω;
• RA-01: Rod Antenna 9 kHz to 30 MHz
• RA-01-HV: Rod Antenna 150 kHz to 30 MHz
• RA-01-MIL: Rod Antenna 9 kHz to 30 MHz
• BC-01: Biconical Antenna (30 – 200 MHz)
• BL-01: Biconical Log Periodic Antenna 30 MHz to 6 GHz
• DR-01: Double-ridged Horn Antenna 6 to 18 GHz
• LP-02: Log Periodic Antenna 200 MHz to 3 GHz
•
LP-03: Log Periodic Antenna 800 MHz to 6 GHz
• LP-04: Log Periodic Antenna 200 MHz to 6 GHz
• VDH-01: Van der Hoofden Test Head 20 kHz to 10 MHz
• TR-01: Antenna Tripod
• Antenna Set AS-02 (BC01+LP02+TR01)
• Antenna Set AS-03 (BC01+LP02+LP03+TR01)
• Antenna Set AS-04 (BC01+LP04+TR01)
• Antenna Set AS-05 (BC01+LP04+DR01+TR01)
• Antenna Set AS-06 (BC01+LP02+LP03+DR01+TR01)
• Antenna Set AS-07 (BL01+TR01)
• Antenna Set AS-08 (BL01+DR01+TR01)
1.6 Other accessories
Of course, the PMM 7010 can be used with other accessories available on the
market, like:
• LISNs, any type;
• Antennas and Loops;
• Near Field Probes;
• Various TEM/GTEM Cells;
• HXYZ 9170 Triple Loop Antenna .
