Installation 2-1
2 - Installation
2.1 Introduction
This section provides the information needed to install your PMM 7010.
It includes the information pertinent to initial inspection and power
requirements, connections, operating environment, instrument mounting,
cleaning, storage and shipment.
2.2 Initial Inspection
2.3 Packing and
Unpacking
When receiving the equipment, first inspect the shipping cardbox for any
damages.
If the shipping box is damaged, it should be kept until the contents of the
shipment have been checked for completeness and the instrument has
been checked mechanically and electrically.
Verify the availability of all the shipped items with reference to the shipping
check list enclosed with the Operating Manual.
Notify any damage to the forwarder personnel as well as to your NARDA
Representative.
To avoid further damage, do not turn on the instrument when there
are signs of shipping damage to any portion of it.
2.4 Preparation for Use
This is a Safety Class I apparatus, and it is also equipped with
protective/functional earth terminals on the rear and front panels. A
good safety/functional ground connection should be provided before
to operate the system.
2.5 Power Supply
The universal adapter supplied with the receiver can work at either 50 Hz
or 60 Hz with a supply voltage rated between 100 and 240 Volt.
It is supplied with different connectors to fit all the possible outlets in
accordance with the various National standards.
+
-
Power supply: DC, 12 V, ~ 800 mA
=> DC Connector
2.5.1 To replace the
mains connector of
the universal
adapter
To replace the mains connector, simply remove the one installed on the
battery charger sliding it off, and insert the one that fits the outlets in use.
