NARDA PMM 7010/00 - Main Specifications

General Information 1-3
1.7 Main Specifications
Table 1-1 lists the PMM 7010 performance specifications.
The following conditions apply to all specifications:
• The ambient temperature shall be -5°C to 45°C
TABLE 1-1 Main Specifications
Electrical Characteristics Performance Limits
Frequency range
Resolution
Frequency accuracy
150 kHz to 1 GHz (Option 00)
9 kHz to 1 GHz (Option 01)
9 kHz to 30 MHz (Option 02)
9 kHz to 3 GHz (Option 03)
10 Hz
< 3 ppm
RF input
VSWR 10 dB RF att.
0 dB RF att.
Attenuator
Pulse Limiter
Z
in
50 Ω, N fem.
< 1,2; < 2 over 1 GHz
< 1,2; <1,4 over 30 MHz; < 2 over 1 GHz
0 dB to 35 dB (5dB steps)
0 dB to 50 dB (2dB steps) over 30 MHz
Built in up to 30 MHz
Max input level
Sinewave AC voltage
Pulse spectral density
(without equipment damage)
140 dBµV (2 W)
100 dBµV/MHz
Preselector (Permanent built-in)
9 kHz to 30 MHz
30 MHz to 1 GHz
1 GHz to 3 GHz
IF bandwidth
6dB bandwidth
CISPR 16-1-1
1 (Opt. 01, 02, 03), 3, 10, 30, 100, 300 kHz, 1 MHz (Opt. 03)
200 Hz (Opt. 01, 02, 03), 9 kHz and 120 kHz
Noise level
(Att. 0 dB, 50  term., Hold Time 1 s)
0,009 to 0,15 MHz < 0 dBuV (QP) (-130 dBm/Hz)
(200 Hz RBW)
< -3 dBuV (AV) (-133 dBm/Hz)
0,15 to 30 MHz < 14 dBuV (QP) (-128 dBm/Hz)
(9 kHz RBW)
< 7 dBuV (AV) (-135 dBm/Hz)
30 to 1000 MHz < 14 dBuV (QP) (-144
dBm/Hz)
(120 kHz RBW)
< 7 dBuV (AV) (-151 dBm/Hz)
