1-4 General Information
1000 to 2700 MHz < 16 dBuV (AV) (-151 dBm/Hz)
(1 MHz RBW)
2700 to 3000 MHz < 19 dBuV (AV) (-148 dBm/Hz)
(1 MHz RBW)
Spurious response
(Att 0dB, 50 term, det. PK, Hold time 10 ms)
< 20 dBµV; < 23 dBµV over 2700 MHz
Detectors
Peak, Quasi-peak, Average, RMS, RMS-Average (optional),
C-Average, Smart Detector function
Level measuring time (hold time)
0,2 ms to 120 s (CISPR 16-1-1 as default)
Display units
With PMM Emission Suite SW
(80 to 200 dB selectable dynamic)
dBm, dBµV, dBµA, dBpW, dBµV/m, dBµA/m, dBpT,
Measurement accuracy
S/N > 20 dB
9 kHz to 1 GHz ± 1,0 dB
1 GHz to 3 GHz ± 1,5 dB
CISPR 16-1-1 conformity
Standard compliant QP detector down to 20 Hz PRF
Demodulation
AM – FM Internal loudspeaker
I/O Interface
USB 2.0; RS-232; User Port (drives PMM LISNs and
accessories)
Operating temperature
-5 °C to 45 °C
Power supply
12 Vdc, 0,8A (AC universal adapter)
Built-in LISN
Frequency range
Continuous rated output current
Max permissible operating voltage
EUT supply frequency range
CISPR equivalent circuit
EUT Power connector
Artificial Hand
9 kHz to 30 MHz
16 A
250 Vac – 350 Vdc
DC to 60 Hz
50 // (5 + 50 H)
Schuko 2P+E
4 mm socket
Dimensions (W x H x D)
235 x 105 x 335 mm
Weight
5,0 kg
