Appendix B Hardware Configuration
© National Instruments Corporation B-9 NI 8352/8353 User Manual
Table B-2. Front Panel Connector Signals
Pin Signal Name Signal Description
1 PWR Power button signal
2 GND Power button +3 V standby
3 Reset Reset button reset
4 GND Reset button ground
5 — —
6 — —
7 Vcc Overheat/fan fail LED Vcc
8 GND Overheat/fan fail LED ground
9 Vcc NIC2 LED Vcc
10 GND NIC2 LED ground
11 Vcc NIC1 LED Vcc
12 GND NIC1 LED ground
13 Vcc HDD LED +5 V
14 GND HD active
15 Vcc Power LED +5 V
16 GND Power LED ground
17 — —
18 — —
19 NMI Nonmaskable interrupt button
control
20 GND Nonmaskable interrupt button
ground
