National Instruments Compact FieldPoint cFP-20 Series User Manual

© National Instruments Corporation A-1 cFP-20xx and cFP-BP-x User Manual
A
Troubleshooting
This appendix gives troubleshooting instructions for the cFP-20xx and
FieldPoint software. For more troubleshooting information, refer to the
Measurement & Automation Explorer Help for FieldPoint and the
Measurement & Automation Explorer Remote Systems Help.
Runaway Startup Application
If a runaway startup application causes the cFP-20xx to become
unresponsive, you must power down the cFP-20xx, then reboot it with
either the DISABLE VI switch or the SAFE MODE switch in the ON
position. Rebooting the controller with the DISABLE VI switch ON
prevents any VIs from running at startup. Rebooting with the SAFE MODE
switch ON starts the cFP-20xx in safe mode, and the embedded LabVIEW
RT engine is not launched. Refer to the DIP Switches section of Chapter 3,
Feature Descriptions, for more information about these DIP switches.
STATUS LED Error Indications
The cFP-20xx indicates specific error conditions by flashing the red
STATUS LED a specific number of times. Table A-1 describes the
STATUS LED flashing sequences and the corresponding error condition.
Table A-1. STATUS LED Flashes and Corresponding Error Conditions
Number of Flashes Error Condition
0 (stays lit) The cFP-20xx did not power on correctly. Contact National Instruments
for assistance.
1 The cFP-20xx is in reset mode or is unconfigured. Make sure the RESET
IP switch is in the OFF position and restart the controller. Refer to the
Measurement & Automation Explorer Help for FieldPoint for more
information about configuration.
2 The cFP-20xx has detected an error in its firmware. This usually occurs
when an attempt to upgrade the firmware is interrupted. Repeat the
firmware upgrade process.
