National Instruments PCI-6035E User Manual

Appendix A Device-Specific Information
© National Instruments Corporation A-29 E Series User Manual
Refer to the Connecting Analog Output Signals section of Chapter 3,
Analog Output, for more information.
AO External Reference
The AO EXT REF input controls the voltage range of analog output signals.
Figure A-27 shows circuitry of the AO EXT REF on BNC DAQPads.
Figure A-27. AO EXT REF
Refer to the
Reference Selection section of Chapter 3, Analog Output, for
more information.
Counter 0 Out and PFI 0/AI Start Trigger
You can access the Counter 0 Out and PFI 0/AI Start Trigger signals
through their respective pins on BNC DAQPads, as shown in the
Figure A-28 and Figure A-29.
Figure A-28. Counter 0 Out
Figure A-29. PFI 0/AI Start Trigger
AO EXT REF
AI GND
CTR 0 OUT
D GND
PFI 0/AI START TRIG
D GND
