Hardware Instructions for Use
16
CC Stimulator Output (isolated)
The CC stimulator output connectors are electronically isolated.
CC Stimulator Output Socket (isolated)
For connection of stimulation electrodes with DIN plugs. Support
for the active handgrip.
HS Link Output Connector
Amplifier Connection
AEP
AEP Headset Connector
VEP
VEP Goggles Connector
Rear Panel
HS Link Output Connector
Amplifier Connection
Protective Earth
Functional Earth
To be used for suppression of noise.
