Amplifiers
Amplifier Module ― 3 Channels
Amplifier Input (isolated)
All amplifier input connectors are electronically isolated.
Electrostatic Sensitive Amplifier Input Connectors
WARNING Do not touch the Amplifier Input
connectors as it may damage the amplifier, or affect its
performance.
Active Electrode – Black
The Active electrode corresponds to the black input
connector.
Reference Electrode – Red
The Reference electrode corresponds to the red input
connector.
Amplifier Input Connectors (1-3)
The amplifier input connectors 1-3 feature both a DIN-type
socket and a pair of 1.5 mm touch-proof connectors.
–See Warning above for the Electrostatic Sensitive Amplifier
Input Connectors.
