Nautel Importer Plus - Page 15

Importer Plus Technical Instruction Manual Description
Issue 0.02 2010-03-29 Page 1-3
Figure 1.4: Typical system with an Importer Plus and Exporter Plus
Note: The Importer Plus and Exporter Plus can also be located at the transmitter site. This requires sending SPS
audio to the transmitter site instead of through a LAN connection.
SPS Audio
MPS Audio
STUDIO
IMPORTER PLUS
EXPORTER PLUS
ETH0
ETH1
FM EXCITER
LAN
TRANSMITTER SITE
To Transmitter
Delayed
MPS Audio
