Importer Plus Technical Instruction Manual Pre-installation tasks
Issue 0.02 2010-03-29 Page 2-1
Section 2: Pre-installation tasks
This section provides a list of tasks that you must perform prior to delivery and installation of the
Importer Plus.
Preparing for installation
To prepare for installation of an Importer Plus, perform the following tasks:
1. Ensure the correct Importer configuration is ordered. Consider the audio card, SPS (analog
or AES), and equipment requirements. For detailed information, see “Configuring the
Importer Plus audio” on page 2-2.
2. Select a location for the Importer Plus in the studio or the transmitter site. For detailed
information, see “Selecting a location for the Importer Plus” on page 2-2.
3. Prepare the network (LAN) connection between the Importer Plus and the NE IBOC,
Exporter or Exporter Plus. Consider the Importer Plus's location and the amount of other
networked equipment at the transmitter site. For detailed information, see “Planning the
LAN connection” on page 2-3.
4. Consult your network manager to obtain IP address information for the Importer Plus, NE
IBOC, Exporter or Exporter Plus, and gateway. For detailed information, see “IP address
information” on page 2-5.
5. If you are going to use SPS sample rate synchronization, determine how it can best be
implemented.
For detailed information, see “Synchronizing the SPS sample rate” on page 2-6.
6. Order any accessories or optional equipment that you may need. See “Parts and tools” on
page 7-1.
7. Train your station technicians and operators on the use of the Importer Plus. For a list of
available technical and user documents, see the About this manual section at the beginning of
this document. For information about Nautel training courses, go to the Nautel website at
http://www.nautel.com/support/training/
CAUTION: FAILURE TO COMPLY WITH RECOMMENDATIONS MAY VOID
YOUR MANUFACTURER’S WARRANTY. FOR MORE INFORMATION, REVIEW
YOUR WARRANTY DOCUMENTS.
