Importer Plus Technical Instruction Manual Troubleshooting
Page 9-4 Issue 0.02 2010-03-29
Parts information
For the purposes of identifying and possibly ordering replacement parts, the Importer Plus’ internal
assemblies are identified in Table 9.2. The table provides the reference designation, a description, and
the Nautel part number for each item.
Table 9.2: Importer Plus Parts List
Reference
Designation
Description Nautel Part #
B1 Fan, 1U LGA775 Side Blow CPU Cooler ZAP49
U1 SBC, PICMG 1.0, LGA775, Core2/P4 UA140
U2 IC, CPU, Core 2 Duo, LGA775,SLA99, E4300 UR104
U3 Memory, 1G, DDR2, 667MHz UX117
U4 Memory, 1G, DDR2, 667MHz UX117
U5 1U Rackmount Chassis, PCI BP, 250W UW107
U6 Sound/Audio Card, Optional
UA100, UA141, UA142, etc.
U7 Sound/Audio Card, Optional UA100, UA141, UA142, etc.
U8 HardDrive, Solid State, 32G,SATA UX111
W1 Cable, SATA, .5m, Straight to Straight UA90
