Importer Plus Technical Instruction Manual Description
Page 1-4 Issue 0.02 2010-03-29
Physical requirements
Figure 1.5: Importer Plus
Dimensions
The Importer Plus is a rack-mountable unit with the following dimensions:
•
Height: 1U, or 4.4 cm (1.75 inches)
• Width: 48.3 cm (19 inches)
• Depth: 44.0 cm (17.3 inches)
Clearances
Ensure there are minimum clearances of 1.3 m (4.0 feet) at the front and the rear of the Importer
Plus's host cabinet to allow room for installation, operation and ventilation. Allow several inches of
clearance at the sides of the Importer Plus.
Weight
The Importer Plus weighs 18 kg (40 lbs).
