Importer Plus Technical Instruction Manual Troubleshooting
Page 9-2 Issue 0.02 2010-03-29
Checking cable connections
Verify that the Importer Plus’ internal cables are connected properly as follows:
1. Remove the Importer Plus’ top cover.
2. Inspect the cables and connections. If a connector is unseated or disconnected, ensure it is
reconnected to its mate as identified in Table 9.1. If necessary, see Figure 9.2 on page 9-3 to
identify the importer's sub-assemblies.
Table 9.1: Internal Connector Mating Information
Connector Mate Notes
P1 U1 CPU12V1
P2 U8 Power
P3 U1 F_PANEL1-RESET Red 12 Black 14
P4 U1 F_PANEL1-PWR BUTTON Red 7 Black 9
P5 U1 F_PANEL1-PWR LED Red 1 Black 5
P6 U1 F_PANEL1-HDD LED Red 11 Black 13
P7 CPU_FAN1
P8 U1_USB00 Red Pin 1
P9 U1_USB01 Black Pin 2
P10 U5_BP_ATXCTL1
P11 U1_ATXCTL1-PS-ON Yellow 2
P12 U1_ATXCTL1-5VSB Red 3
W1P1 U1 SATA1
W1P2 U8 SATA
