Nautilus T616 User Manual

15
5. Attach the Console to Frame Assembly and Connect the Cables
NOTICE: Be sure that the hooks on each side of the Console are seated in the notches on the Uprights. Remove the
ziptie and rubberbands that attach the Cables. Do not crimp the Cables.
Do not fully tighten Hardware until instructed.
1
6mm
F
D
E
X4
E
F
C
X2
6mm

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
