Nautilus T616 User Manual

27
Console Features
The Console provides important information about your workout and lets you control the resistance levels while you
exercise.TheConsolefeaturestouchcontrolbuttonstonavigateyouthroughtheexerciseprograms.
Console Display
Pacer Icon- represents the location of the Pacer during the Workout.
User Indicator Lights- The User indicator lights show where the User is in relation to the Pacer during the Workout.
FitnessScoreDisplay-TheFitnessScoreDisplayshowsthecurrentFitnessScoreoftheselectedUserProle.
GoalDisplay-TheGoalDisplayshowstheselectedtypeofgoal(Distance,TimeorCalories)andthevalueforit.
User Placement Display- The User Placement Display shows the difference between the User and the Pacer. The arrows
telliftheUserisinfront(UParrow)orbehind(DOWNarrow)thePacer.
COMPARE button- Push to select the desired Workout Pacer: Average, Best, or off.
USERbutton-PushtoselectthedesiredUserProle.TheActiveUserDisplaywilladjust
Increase ()button-Increasesthecurrentvalueormovesthroughtheoptionsavailable
Left ()button-Shiftsthecurrentlyactivesegment,andmovesthroughoptions
OKbutton-Conrmsinformationoraselection
Fan Button
Fitness Score Display Goal Display
User Indicator
Lights
Pre-Set
Incline
Buttons
User Placement
Display
Incline Enter
Button
Pre-Set
Speed
Buttons
Speed Enter
Button
Pacer Icon

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
