Nautilus T624 Service Manual

119
Note: Make sure the treadmill is located on a surface that is easy to clean.
22. Make sure that there is safe clearance around, on and above the treadmill.
Make sure there is no object to spill or cause blockage from the fully folded
position.
Be sure there is adequate height clearance for the raised deck.
23. Using the support bar found below the rear of the walking belt, lift the walk-
ing deck fully upward and engage the hydraulic lift. Be sure that the hydraulic
lift is correctly locked in place. You will hear an audible click when the hydraulic
lift shifts into the locked position.
Use proper safety precautions and lifting techniques. Bend your knees
and elbows, keep your back straight and pull up equally with both arms.
Make sure that your own physical strength is capable of lifting the
walking deck until it engages the locking mechanism. Use a second
person if necessary.
Do not use the walking belt or rear roller to lift the treadmill. These parts
do not lock in place and can abruptly move. Injury to you or damage to
the machine can occur.
24. Make sure that the locking mechanism is engaged. Carefully pull back on
the walking deck and make sure that it does not move. When you do this, keep clear of movement path in case the treadmill lock is not engaged.
Do not lean against the treadmill when it is folded. Do not put items on it that could cause it to become unstable or fall.
25.Applyafewdropsofthelubricanttotheinnersurfaceofthebeltfortheentirewidthofthebelt.Averythinlayerofsiliconelubricantontheentire
deck below the belt is desired.
NOTICE: Always use a silicone-based lubricant such as the lubricant supplied with the machine. Do not use a degreaser like WD-40
®
as
this could seriously impact performance. We can recommend that you use the following:
  •8300SiliconeSpray,availableatmostHardwareandAutoPartsstores.
  •Lube-N-Walk
®
TreadmillLubricationKit,availablefromyourlocalspecialtytnessdealerorlocaldistributor.
26. Manually rotate the belt 1/2 of the length of the belt and apply lubricant again.
27.Makesurethereissufcientspacetolowerthewalkingdeck.
Keep a minimum clearance behind the machine of 2 m (79”) and 0.6 m (24”)
on each side. This is the recommended safe distance for access, movement
and emergency dismounts from the machine.
28. Make sure there is no object on or around the treadmill to spill or cause blockage
from the fully unfolded position.
29. Slightly push the walking deck forward toward the console. With your foot lightly
push the top part of the hydraulic lift forward until the locking tube releases and you
can pull the walking deck away from the console. Hold up the rear of the walking
deck, and move to the side of the machine.
Keep clear of the movement path of the walking deck.

Nautilus T624 Specifications

General

Quantity per pack	1 pc(s)
Foldable	Yes
Bluetooth	No
Incline range	0 - 12 %
Maximum speed	19.3 km/h
Minimum speed	0 km/h
Product color	Black, Grey
Number of programs	22
Maximum user weight	136 kg
Backlight color	Blue

Weight and Dimensions

Width	- mm
Weight	- g
Running area (W x L)	20 x 55 mm
Running belt thickness	1.5 mm
Running deck thickness	19 mm
