Nautilus T624 Service Manual

135
on the walking deck and make sure that it does not move. When you do this, keep
clear of movement path in case the treadmill lock is not engaged.
Do not lean against the treadmill when it is folded. Do not put items on it that
could cause it to become unstable or fall.
7. Using a #2 Phillips screwdriver, remove the indicated screw from the Rear Roller
Cover.
8. Remove the Rear Roller Cover.
9. Using a #2 Phillips screwdriver, remove the 6 indicated screws from below the
Walking Deck that attach the Right Side Rail.
10. Remove the Right Side Rail from the Walking Deck.

Nautilus T624 Specifications

General

Quantity per pack	1 pc(s)
Foldable	Yes
Bluetooth	No
Incline range	0 - 12 %
Maximum speed	19.3 km/h
Minimum speed	0 km/h
Product color	Black, Grey
Number of programs	22
Maximum user weight	136 kg
Backlight color	Blue

Weight and Dimensions

Width	- mm
Weight	- g
Running area (W x L)	20 x 55 mm
Running belt thickness	1.5 mm
Running deck thickness	19 mm
