Nautilus T624 - HARDWARE AND TOOLS

10
Tools
Included
Item Qty Description Item Qty Description
A 4 SocketHeadHexScrew,M8x50 D
10
SelfTappingScrew,M3.9x16
B 8 SocketHeadHexScrew,M8x16 E
12
LockWasher,M8
C
2
PhillipsHeadScrew,M5x14 F
12
FlatWasher,M8
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remain-
ing Hardware after the proper assembly of your machine.
A B D
C E F
HARDWARE / TOOLS
#2
6 mm
6 mm
