Nautilus T624 - SPECIFICATIONS AND ASSEMBLY PREPARATION; Before Assembly; Basic Assembly Tips

8
SPECIFICATIONS / BEFORE ASSEMBLY
Maximum User Weight:  136kg(300lbs)
Total Surface Area (footprint) of equipment:16387cm
2
Power Requirements:
Operational Voltage: 220V - 240V AC, 50Hz
 OperatingCurrent:  8A
Maximum Inclined Deck Height: 38.4cm(15.1inches)
Assembled Weight:  Approx.90.7kgs(200lbs)
Sound Emission: Less than 70 db average without
load. Noise emission under load is higher than without load.
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a
hard,levelsurface.Allowaworkoutareaofaminimum211.3cmx384cm(83.2”x151.2”).Besurethattheworkout
spaceyouareutilizinghasadequateheightclearance,takingintoconsiderationtheheightoftheuserandthemaximum
incline of the machine.
Basic Assembly Tips
Follow these basic points when you as-
semble your machine:
• Read and understand the “Important
Safety Instructions” before assembly.
• Collect all the pieces necessary for each
assembly step.
• Using the recommended wrenches, turn
the bolts and nuts to the right (clock-
wise)totighten,andtheleft(counter-
clockwise)toloosen,unlessinstructed
otherwise.
• When attaching 2 pieces, lightly lift and
look through the bolt holes to help insert
the bolt through the holes.
• The assembly can require 2 people.
146.3 cm
57.6”
89.4 cm
( 35.2” )
183.3 cm
72.2”
2.11m
( 83.2
” )
0.6m
( 24” )
2m
( 79” )
0.6m
( 24” )
3.84m ( 151.2” )
DO NOT dispose of this product as refuse. This product is to be recycled. For proper disposal of this product,
please follow the prescribed methods at an approved waste center.
