9
DISPLAY LAYOUT
Symbol Line
Symbol Description
Ringer off (Silence)
Signal strength is good if at least 2 bars are visible
On : active on a call, Flashing : incoming call
Battery charging status
(see Page 7)
Text L ines
The text lines display the information on the current call status or menu lists and
texts. In the idle state, it displays the system name with extension number and user
name.
Soft Key Line
Symbol Description
Use to select the desired call from Redial List.
Move the cursor by pressing Scroll Keys in order to select the
desired call or menu.
Move the cursor to the beginning or end of the entry by pressing
Scroll Keys.
Illumination (Back-Light)
The display is automatically illuminated when there is an incoming call or when
you press a key. The illumination is switched off again automatically about 10 sec
after the last key was pressed.
Symbol Line
Text Lines (3 Lines)
Soft Key Line
TelBook
ABC CORP
Menu
MIKE
208
To Next Page
