8
Checking the Supplied Items and the Names of the Projector Parts
䡵 Connection terminals
1. USB port (Type A) (USB A)
This port is for future extension.
2. USB port (Type B) (USB B)
Use this port when controlling your projector in USB connection from a PC. Use a commercially
available USB cable to connect the projector to the PC.
3. Remote control terminal (REMOTE 1)
Connect the remote control of the projector, using the supplied remote control cable.
NOTE
• You cannot operate the remote control of your projector unless it is connected by the remote control cable.
4. PC control terminal (PC CONTROL) (Mini D-Sub 9P)
Use this terminal when controlling your projector in serial connection from a PC. Use a commercially
available RS-232C straight cable to connect the projector to the PC.
123 4 5
6789 10 11 13
12
To Next Page
