NEC ITK-8TCGX User Manual

37
1.
(10) Select 2 (Password).
(11) Enter a password with the digit keys.
(12) Select 3 (Folder).
(13) Enter the folder name where the download file is
stored.
❍ Enter the name of the folder where the files are
stored in the server (including the path from root
directory to the folder where the backup file is
stored).
(14) Press the Left key or the Back softkey
(15) Select 3 (Server Address).
(16) Enter the IP address of FTP/TFTP/HTTPS server
using the digit keys.
Use Asterisk key for separator of IP address.
To enter the address (URI) of FTP/TFTP/HTTPS,
press Soft key (IP/URI) to switch the display to
the URI input screen.
❍ Press the IP/URI softkey.
❍ Using the Dial keys, enter the address (URI) of the
server where the files are stored.
(17) Select 1
( Data Backup).
(18) Enter the file name using the digit keys/
The default name is displayed.
❍ Press the BK softkey once to delete the default file
name.
❍ Enter the file name that for the backup file.
Refer to Appendix B Input Characters for
entering instructions for entering characters.
Refer to Appendix B Input Characters for
entering instructions for entering characters.
Refer to Appendix B Input Characters for
entering instructions for entering characters.
Refer to Appendix B Input Characters for
entering instructions for entering characters.
The IP address input screen can be switched to
a URI input screen using the IP/URI softkey.
❍ Press the IP/URI softkey.
❍ Press the IP/URI again to go back to the
IP address input screen.
Refer to Appendix B Input Characters for
entering instructions for entering characters.
Up to 64 characters can be entered as a file
name.
When you send the data from the terminal to
the server, you can select the file format with
encryption.
❍ Press the Enc softkey to send the file with
encryption.
❍ Press the No Enc softkey to send the file
without encryption.
