6. Installation and Connections
3
2
1
Thissectiondescribeshowtosetupyourprojectorandhowtoconnectvideoandaudiosources.
Yourprojectorissimpletosetupanduse.Butbeforeyougetstarted,youmustrst:
z Setupascreenandtheprojector.
x Connectyourcomputerorvideoequipment
totheprojector.
(→page104, 106, 107, 108, 109, 110, 111)
c
 Connect the supplied power cord.
(→page15)
NOTE:
• Ensurethatthepowercordandanyothercablesare
disconnected before moving the projector. When
movingtheprojectororwhenitisnotinuse,cover
thelenswiththeslidinglenscover.
• An optional cable cover (NP01CV) is available for
theM420X,M420XV,M350XS,M300XS,M260XS,
M300WS,andM260WS.Refertopage114forat-
tachingthecablecover.
1 Setting Up the Screen and the Projector
Selecting a Location
[M350X/M300X/M260X/M230X]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeis
approximately25"(0.64m)measureddiagonallywhentheprojectorisroughly35inches(0.9m)fromthewallor
screen.Thelargesttheimagecanbeis300"(7.6m)whentheprojectorisabout435inches(11.0m)fromthewall
or screen.
300"
240"
Distance
(Unit: m/inch)
Lens center
Screen Size
Screen Size (Unit: cm/inch)
200"
180"
150"
120"
100"
80"
11.0/435
"
8.8/348
"
6.6/260
"
5.5/216
"
4.4/173
"
3.6/144
"
2.9/115
"
2.2/86
"
1.4/57
"
40"
7.3/289
"
60"
30"
25"
1.1/
42
"
0.9/
35
"
609.6(W)�457.2(H) / 240(W)�180(H)
487.7(W)�365.8(H) / 192(W)�144(H)
406.4(W)�304.8(H) / 160(W)�120(H)
304.8(W)�228.6(H) / 120(W)�90(H)
365.8(W)�274.3(H) / 144(W)�108(H)
243.8(W)�182.9(H) / 96(W)�72(H)
203.2(W)�152.4(H) / 80(W)�60(H)
162.6(W)�121.9(H) / 64(W)�48(H)
121.9(W)�91.4(H) / 48(W)�36(H)
81.3(W)�61.0(H) / 32(W)�24(H)
61.0(W)�45.7(H) / 24(W)�18(H)
50.8(W)�38.1(H) / 20(W)�15(H)
TIP:
• Thedistancesareindicatedbyintermediatevaluesbetweenteleandwide.Useasaruleofthumb.
• Formoredetailsonthrowdistance,seepage101.
To the wall outlet.
