6. Installation and Connections
Connecting Component Input
 Acomponentsignalwillbeautomaticallydisplayed.Ifnot,fromthemenu,select[SETUP]→[OPTIONS(1)]→
[SIGNALSELECT]→[COMPUTER1]or[COMPUTER2],andthenplaceacheckmarkintheComponentradio
button.
• Selectthesourcenameforitsappropriateinputconnectorafterturningontheprojector.
Inputconnector
SOURCEbuttonontheprojector
cabinet
Buttonontheremotecontrol
COMPUTER1IN COMPUTER1 (COMPUTER1)
COMPUTER2IN COMPUTER2 (COMPUTER2)
NOTE:RefertoyourDVDplayer’sowner’smanualformoreinformationaboutyourDVDplayer’svideooutputrequirements.
NOTE:TheM420XVdoesnotcomewiththeAUDIOINconnector.
AUDIOIN
LR
AUDIOOUT
L R
Component
Y Cb Cr
AUDIOIN
COMPUTER1IN
COMPUTER1IN
Audio cable (not supplied)
15-pin - to - RCA (female) × 3
cable adapter (ADP-CV1E)
Stereo mini plug - to - RCA
audio cable (not supplied)
Component video
RCA × 3 cable (not
supplied)
DVD player
Audio Equipment
M420XV
