NEC M230X - Rear

6
1. Introduction
Rear
[M350X/M300X/M260X/M230X/M300W/M260W]
[M420X/M420XV]
AC Input
Connect the supplied power cord’s
three-pin plug here, and plug the
other end into an active wall outlet.
(→ page 15)
Port Cover for Optional USB
Wireless LAN Unit
When using the optional USB
Wireless LAN Unit, first remove
the cover. (→ page 111)
Terminal Panel (→ page 9)
MonauralSpeaker(10W)
Lamp Cover (→ page 121)
Rear Foot (→ page 20)
Built-in Security Slot (
)*
Security chain opening
Attach an anti-theft device.
The security chain opening accepts
security wires or chains up to 0.18
inch/4.6 mm in diameter.
AC Input
Connect the supplied power cord’s
three-pin plug here, and plug the
other end into an active wall outlet.
(→ page 15)
Connection for cable cover (Left/
right)
Screw holes temporarily fixing
grooves for the optional cable cover
(→ page 114)
Port Cover for Optional USB
Wireless LAN Unit
When using the optional USB
Wireless LAN Unit, first remove
the cover. (→ page 111)
Terminal Panel (→ page 9)
MonauralSpeaker(10W)
(The M420XV does not come with
thespeaker.)
Lamp Cover (→ page 121)
Rear Foot (→ page 20)
Security chain opening
Attach an anti-theft device.
The security chain opening accepts
security wires or chains up to 0.18
inch/4.6 mm in diameter.
Built-in Security Slot (
)*
* ThissecurityslotsupportstheMicroSaver
®
Security System.
