NEC M230X - Making Connections; Connecting Your Computer

104
6. Installation and Connections
COMPUTER 1 IN COMPUTER 1 IN HDMI INUSB(PC)AUDIO IN
HDMI IN
USB(PC)
Computer cable (VGA) (supplied)
To mini D-Sub 15-pin connector on the projector. It is
recommended that you use a commercially avail-
able distribution amplifier if connecting a signal cable
longer than the cable supplied.
A commercially available
USB cable
(compatible with USB 2.0
specifications)
NOTE: For Macintosh, use a commercially available pinadapter (not
supplied)toconnecttoyourMac’svideoport.
Stereo mini-plug
audio cable (not
supplied)
 Making Connections
NOTE:WhenusingwithanotebookPC,besuretoconnecttheprojectorandnotebookPCwhiletheprojectorisinstandbymode
andbeforeturningonthepowertothenotebookPC.
InmostcasestheoutputsignalfromthenotebookPCisnotturnedonunlessconnectedtotheprojectorbeforebeingpoweredup.
* Ifthescreengoesblankwhileusingyourremotecontrol,itmaybetheresultofthecomputer’sscreen-saverorpowermanage-
mentsoftware.
Enabling the computer’s external display
DisplayinganimageonthenotebookPC’sscreendoesnotnecessarilymeanitoutputsasignaltotheprojector.
WhenusingaPCcompatiblelaptop,acombinationoffunctionkeyswillenable/disabletheexternaldisplay.
Usually,thecombinationofthe“Fn”keyalongwithoneofthe12functionkeysgetstheexternaldisplaytocomeon
oroff.Forexample,NEClaptopsuseFn+F3,whileDelllaptopsuseFn+F8keycombinationstotogglethrough
externaldisplayselections.
Connecting Your Computer
NOTE:SignalssupportedbyPlug&Play(DDC2)
INPUT
COMPUTER 1 IN COMPUTER 2 IN HDMI
analog analog digital
Yes Yes Yes
HDMI cable (not supplied)
Use High Speed HDMI
®
Cable.
NOTE: The M420XV does not come with the
AUDIOINconnector(stereominijack).
M420XV
