NEC M230X - Cabinet Dimensions

136
8. Appendix
257 (10.1)
99 (3.9)
339 (13.4)
100 (3.9)
108 (4.3)
59.4
(2.34)
175 (6.9)
200 (7.9)
150 (5.9) 130 (5.1)
 Cabinet Dimensions
[M350X/M300X/M260X/M230X/M300W/M260W]
Lens center
Lens center
Holes for ceiling mount
Unit:mm(inch)
