NEC M230X - Attaching the Optional Cable Cover (NP01 CV)

114
6. Installation and Connections
Attaching the Optional Cable Cover (NP01CV)
Anoptionalcablecover(NP01CV)isavailableforhidingcables.
TheNP01CVcablecoverisdesignedforusewiththeM420X,M420XV,M350XS,M300XS,M260XS,M300WS,and
M260WS.
CAUTION:
• Besuretotightenthescrewsafterattachingthecablecover.Failuretodosomaycausethecablecovertocome
offandfall,resultingininjuryordamagetothecablecover.
• Donotputbundledcablesinthecablecover.Failuretodosomaydamagethepowercord,resultingare.
Attachingthecablecover
Attachthecablecoverafterinstallingtheprojectorontheceilingandconnectingcables.
Toolneededforattaching:
• Phillipsscrewdriver(plus-head)
1. Aligntwotabsontheoutsideofthecablecoverwithgroovesoftheprojectorandpushthetopend.
1
2
1
Tabs
• Atthesametimetwotabsontheinsideofthecablecoverwillbeengagedintherespondinggroovesofthe
projector.
NOTE:
• Becarefulnottogetcablescaughtinbetweenthecablecoverandtheprojector.
2. Tightenthecablecoverscrews.
• Besuretotightenthescrews.
1
2
Removingthecablecover
1. LoosenthecablecoverscrewsuntilthePhillipsscrewdrivergoesintoafreewheelingcondition
2. Remove the cable cover.
Push up the cable cover slightly and rotate it to release.
