NEC M230X - Part Names of the Remote Control

10
1. Introduction
 Part Names of the Remote Control
3
7
5
6
1
2
10
15
16
14
17
9
4
8
13
29
30
31
19
20
25
27
28
24
18
23
22
21
26
32
12
11
1. Infrared Transmitter
(→page11)
2. POWER ON Button
(→page16)
3. POWEROFFButton
(→page27)
4,5,6.COMPUTER1/2/3Button
(→page18)
 (COMPUTER3buttonisnotavailable.)
7. AUTOADJ.Button
(→page26)
8. VIDEOButton
(→page18)
9. S-VIDEOButton
(→page18)
10.HDMIButton(→page18)
11.VIEWERButton(→page18, 60)
12.NETWORKButton(→page18)
13.USBDISPLAYButton(→page18)
14.IDSETButton
(→page86)
15.NumericKeypadButton/CLEARButton
(→page86)
16.FREEZEButton
(→page29)
17.AV-MUTEButton
(→page29)
18. MENU Button
(→page69)
19.EXITButton(→page69)
20. Button (→
page69)
21. ENTER Button (→page69)
22.D-ZOOM(+)(–)Button
(→page29)
23.MOUSEL-CLICKButton*
(→page41)
24.MOUSER-CLICKButton*
(→page41)
25.PAGE/Button*
(→page41)
26.ECOButton(→page30)
27.KEYSTONEButton
(→page25)
28. PICTURE Button
(→page74, 76)
29.VOL.(+)(–)Button
(→page26)
30.ASPECTButton
(→page79)
31.FOCUS/ZOOMButton
 TheZOOMbuttonworksontheshort-throwmodels
only.TheFOCUSbuttondoesnotworkonthisseries
ofprojectors.
32.HELPButton
(→page94)
* ThePAGE/, ,MOUSEL-CLICKandMOUSER-CLICKbuttonsworkonlywhenaUSBcableisconnected
withyourcomputer..
