79
5. Using On-Screen Menu
SelectingAspectRatio[ASPECTRATIO]
Theterm“aspectratio”referstotheratioofwidthtoheightofaprojectedimage.
Theprojectorautomaticallydeterminestheincomingsignalanddisplaysitinitsappropriateaspectratio.
•Thistableshowstypicalresolutionsandaspectratiosthatmostcomputerssupport.
Resolution AspectRatio
VGA  640×480  4:3
SVGA
 800×600  4:3
XGA
 1024×768  4:3
WXGA
 1280×768  15:9
WXGA
 1280×800  16:10
WXGA+
 1440×900  16:10
SXGA
 1280×1024  5:4
SXGA+
 1400×1050  4:3
UXGA
 1600×1200  4:3
Options Function
AUTO
Theprojectorwillautomaticallydeterminetheincomingsignalanddisplayitinitsaspect
ratio.(→ nextpage)
Theprojectormayerroneouslydeterminetheaspectratiodependingonitssignal.Ifthis
occurs,selecttheappropriateaspectratiofromthefollowing.
4:3 Theimageisdisplayedin4:3aspectratio.
16:9 Theimageisdisplayedin16:9aspectratio.
15:9 Theimageisdisplayedin15:9aspectratio.
16:10 Theimageisdisplayedin16:10aspectratio.
WIDEZOOM
(M350X/M300X/M260X/
M230X/M420X/M420XV/
M350XS/M300XS/
M260XS)
Theimageisstretchedleftandright.
Partsofthedisplayedimagearecroppedattheleftandrightedgesandthereforenot
visible.
LETTERBOX
(M300W/M260W/
M300WS/M260WS)
Theimageofaletterboxsignalisstretchedequallyinthehorizontalandverticaldirections
totthescreen.Partsofthedisplayedimagearecroppedatthetopandbottomedges
andthereforenotvisible.
NATIVE Theprojectordisplaysthecurrentimageinitstrueresolutionwhentheincomingcomputer
signalhasalowerresolutionthantheprojector’snativeresolution.
[Example 1]Whentheincomingsig-
nalwiththeresolutionof800×600
isdisplayedon the M350X/M300X/
M260X/M230X/M420X/M420XV/
M350XS/M300XS/M260XS:
[Example 2]Whentheincomingsig-
nalwiththeresolutionof800×600
isdisplayedontheM300W/M260W/
M300WS/M260WS:
NOTE:
• Whenanon-computersignalisdisplayed,the[NATIVE]isnotavailable.
• Whenasignalwithahigherresolutionthantheprojector’snativeresolutionisdisplayed,[NATIVE]
isnotavailable.
