NEC M230X - Connecting Your DVD Player or Other AV Equipment

107
6. Installation and Connections
Connecting Your DVD Player or Other AV Equipment
ConnectingVideo/S-VideoInput
• Selectthesourcenameforitsappropriateinputconnectorafterturningontheprojector.
Inputconnector
SOURCEbuttonontheprojector
cabinet
Buttonontheremotecontrol
VIDEOIN
VIDEO
(VIDEO)
S-VIDEOIN
S-VIDEO
(S-VIDEO)
NOTE:
• TheAUDIOINLandRjacks(RCA)aresharedbetweentheVideoandS-Videoinputs.
• TheM420XVdoesnotcomewiththeAUDIOINconnectors(RCA).
NOTE:RefertoyourVCRowner’smanualformoreinformationaboutyourequipment’svideooutputrequirements.
NOTE:AnimagemaynotbedisplayedcorrectlywhenaVideoorS-Videosourceisplayedbackinfast-forwardorfast-rewindvia
ascanconverter.
AUDIO OUTVIDEO OUT
S-VIDEO VIDEO LR
AUDIO IN
LR
S-VIDEO IN
VIDEO IN
S-VIDEO IN
VIDEO IN
AUDIO IN
Audio cable (not supplied)
S-Video cable (not supplied)
Video cable (not supplied)
Audio equipment
Audio cable (not supplied)
M420XV
