2. Projecting an Image (Basic Operation)
 Adjusting the Picture Size and Position
Usetheadjustabletiltfoot,thezoomfunctionorthefocusfunctiontoadjustthepicturesizeandposition.
In this chapter drawings and cables are omitted for clarity.
Adjustingthethrowangle(theheightofanimage)
[Tiltfoot](→page20)
Adjustingtheleftandrighttiltofanimage
[Rearfoot](→page20)
Finelyadjustingthesizeofanimage
[Zoomfunction](→page21)
Adjustingthefocus
[Focusfunction](→page23)
Adjustingthekeystonecorrection[KEYSTONE]*(→page24)
AutomaticKeystoneCorrectionfunctionisturnedonatthetimeofshipment.
Toperformkeystonecorrectionmanually,see“6.CorrectingKeystoneDistortionManually”onpage24.
