NEC M230X - Page 112

102
6. Installation and Connections
[M300W/M260W]
Screen Size
B
C
D
α
Diagonal Width Height wide tele wide tele
inch mm inch mm inch mm inch mm inch mm - inch mm inch mm degree - degree
25 635 21 538 13 337 5 139 27 687 - 46 1172 -1 -29
11�4 - 6�8
30 762 25 646 16 404 7 167 33 833 - 56 1415 -1 -35 11�3 - 6�7
40 1016 34 862 21 538 9 222 44 1126 - 75 1902 -2 -47 11�2 - 6�7
60 1524 51 1292 32 808 13 333 67 1712 - 113 2876 -3 -71 11�0 - 6�6
72 1829 61 1551 38 969 16 400 81 2064 - 136 3461 -3 -85 11�0 - 6�6
80 2032 68 1723 42 1077 17 444 90 2298 - 152 3850 -4 -94 10�9 - 6�6
84 2134 71 1809 45 1131 18 466 95 2415 - 159 4045 -4 -99 10�9 - 6�6
90 2286 76 1939 48 1212 20 500 102 2591 - 171 4337 -4 -106 10�9 - 6�6
100 2540 85 2154 53 1346 22 555 114 2884 - 190 4824 -5 -118 10�9 - 6�6
120 3048 102 2585 64 1615 26 666 137 3470 - 228 5798 -6 -141 10�9 - 6�6
150 3810 127 3231 79 2019 33 833 171 4349 - 286 7259 -7 -177 10�8 - 6�5
180 4572 153 3877 95 2423 39 1000 206 5228 - 343 8720 -8 -212 10�8 - 6�5
200 5080 170 4308 106 2692 44 1111 229 5814 - 382 9694 -9 -236 10�8 - 6�5
210 5334 178 4523 111 2827 46 1166 240 6107 - 401 10181 -10 -247 10�8 - 6�5
240 6096 204 5169 127 3231 52 1333 275 6986 - 458 11642 -11 -283 10�8 - 6�5
270 6858 229 5816 143 3635 59 1499 310 7865 - 516 13103 -13 -318 10�8 - 6�5
300 7620 254 6462 159 4039 66 1666 344 8744 - 573 14564 -14 -353 10�8 - 6�5
[M350XS/M300XS/M260XS]
Screen Size
B
C
D
α
Diagonal Width Height wide wide
inch mm inch mm inch mm inch mm inch mm inch mm degree
60 1524 48 1219 36 914 18 457 23 573 0 0
38�6
72 1829 58 1463 43 1097 22 549 28 700 0 0 38�1
80 2032 64 1626 48 1219 24 610 31 784 0 0 37�9
84 2134 67 1707 50 1280 25 640 33 827 0 0 37�7
90 2286 72 1829 54 1372 27 686 35 890 0 0 37�6
100 2540 80 2032 60 1524 30 762 39 996 0 0 37�4
110 2794 88 2235 66 1676 33 838 43 1101 0 0 37�3
[M300WS/M260WS]
Screen Size
B
C
D
α
Diagonal Width Height wide wide
inch mm inch mm inch mm inch mm inch mm inch mm degree
56�2 1427 48 1211 30 757 18 454 22 569 3 76 38�6
60 1524 51 1292 32 808 19 485 24 611 3 81 38�4
70 1778 59 1508 37 942 22 565 28 723 4 94 38�0
80 2032 68 1723 42 1077 25 646 33 835 4 108 37�7
90 2286 76 1939 48 1212 29 727 37 947 5 121 37�5
100 2540 85 2154 53 1346 32 808 42 1059 5 135 37�3
104 2642 88 2240 55 1400 33 840 43 1104 6 140 37�3
