132
8. Appendix
ModelNumber M420X/M420XV
Optical
M420X M420XV
LCDPanel 0.63inchLCDwithMicroLensArray(AspectRatio4:3)
Resolution*
1
1024×768pixels(XGA)
Lens Manualzoomandfocus
ZoomRatio=1.7
F1.7–2.0 f=19.8–23.7mm
Lamp 265WAC
(195WinECO1)
LightOutput*
2
*
3
4200 lumens
ECO1:75%
ContrastRatio*
3
(fullwhite:fullblack)
2000:1
ImageSize(Diagonal) 25–300inches/0.64m–7.6m
ProjectionDistance
(Min.–Max.)
25–542inches/0.64–13.8m
ProjectionAngle 10.7°–11.6°(wide)/
6.5°–6.8°(tele)
*1 Effectivepixelsaremorethan99.99%.
*2 Thisisthelightoutputvalue(lumens)whenthe[PRESET]modeissetto[HIGH-BRIGHT].Ifanyothermodeisselectedasthe
[PRESET]mode,thelightoutputvaluemaydropslightly.
*3 CompliancewithISO21118-2005
Electrical
M420X M420XV
Inputs
2×RGB/Component(D-Sub15P),1×HDMIType
A(HDMI
®
Connector)HDCPsupported*
4
,
1×S-Video(DIN4P),1×Video(RCA),1×(L/R)
RCAAudio,2×StereoMiniAudio
2×RGB/Component(D-Sub15P),1×HDMIType
A(HDMI
®
Connector)HDCPsupported*
4
,
1×S-Video(DIN4P),1×Video(RCA)
Outputs 1×RGB(D-Sub15P),1×StereoMiniAudio 1×RGB(D-Sub15P)
PCControl 1×PCControlPort(D-Sub9P)
WiredLANPort 1×RJ-45(10BASE-T/100BASE-TX)
WirelessLANPort
(Optional)
IEE802.11b/g/n(optionalWirelessLANUnit[NP02LMSeries]required)
USBPort 1×TypeA,1×TypeB
ColorReproduction 10-bitsignalprocessing(1.07billioncolors)(VIEWER,NETWORK:Colors,16.7millioncolors)
CompatibleSignals*
5
Analog:VGA/SVGA/XGA/XGA+/WXGA/WXGA+/SXGA/SXGA+/UXGA
480i/480p/576i/576p/720p/1080i/1080p
HDMI:VGA/SVGA/XGA/WXGA/SXGA/480p/576p/720p/1080i/1080p
VideoBandwidth RGB:80MHz(Max.)
HorizontalResolution 540TVlines:NTSC/NTSC4.43/PAL/PAL-M/PAL-N/PAL60
300TVlines:SECAM
ScanRate Horizontal:15kHzto100kHz(RGB:24kHzorover)
Vertical:50Hzto120Hz(HDMI:50Hzto85Hz)
SyncCompatibility SeparateSync
Built-inSpeaker 10W(monaural) Nospeaker
PowerRequirement 100–240VAC,50/60Hz
InputCurrent 3.9–1.7A
