NEC MultiSync FP1350 - User Control Operation

8-26
5) User Control Operation
User Control Interface (IC801)
Table 5 Input (IC801)
Pushed SW pin 33 pin 32 pin 34 pin 31 pin 30 pin 29 pin 28 pin27
EXIT Low High High High High High High High
- High Low High High High High High High
6
High High Low High High High High High
5
High High High Low High High High High
+ High High High High Low High High High
PROCEED High High High High High Low High High
RESET High High High High High High Low High
BNC/D-SUB High High High High High High High Low
a. OSD
This model is adjusted through OSD ( On Screen Display ; it is called OSM
TM
in the USA), by operating
Control Panel. It is located on the lower center of front panel.
-
6
5
+
PROCEED
RESET
EXIT
BNC/D-SUB
(Fig. 6.2) Control Panel
